High End Loudspeaker components and Kits
Featured products...
New DEQX HDP-4 and HDP-EXPRESS ll -
Free bonus 2 way mini-monitor driver kit and accessories included with your purchase of a HDP-4. More info will be posted shortly.
We offer full support including correction files from your measurements that you can load up in your system to get you up quickly...
Master the art of timing
DEQX processors correct the distortion that all speakers make and offer room compensation as an added extra. While righting frequency-response errors as other units do, they also uniquely fix critical timing errors by adjusting thousands of frequency groups so that they arrive on time. Other room correction devices simply adjust amplitude response (uneven output at different frequencies) to offset room modes. But they can’t address the fine details of phase coherence; the group-delay timing issues that manifest in all real-world speakers.The results are startling; two-channel and surround systems open up in a dramatic way when timing, phase and amplitude accuracy are restored to the speakers, with judicious room compensation added.
DEQX HDP-4 - visit the Manufacturer's website
- more info
Raven Line Source specifications;
Ribbon Material................pure MMX, no plastic film.
Ribbon Mass....................0.05 grams
Ribbon Width..................15 mm
Ribbon length.................264 mm
Ribbon Area....................39.6 cm^2
On a 15 inch wide asymmetric cabinet, +/- 1.5 dB from 500 Hz to 40 kHz.
Recommended crossover...800 Hz, 24 dB Linkwitz-Riley.
Impedance......................7 ohms above 400 Hz.
DCR...............................0.05 ohm
Sensitivity.......................97 dB , 2.83 volts at 1 meter.
Power handling with recommended crossover 30 watts at 800 Hz.
Speaker system power up to 250 Watts.
Face Dimension..........134 mm wide, 308 mm tall, 8 mm thick
Cabinet hole..............102 mm wide, 283 mm tall, 130 mm deep
Weight....................26 pounds
MMX is a new type of ribbon, exclusive to RAVEN, that has about 6 times the strength of pure aluminum ribbons. MMX has a much stronger centering force to reduce distortion, increase power handling and improve durability.
The Raven Line Source has a 250 Hz resonance frequency thanks to a very large rear air chamber that is 3 inch deep by 2.5 inch wide.
The rear chamber is lined with 12 mm thick real wool felt and filled with 50 mm thick Black Hole Stuff to completely absorb the rear wave without reflections. The water fall decay and impulse response are excellent!
The transformer is internal with shortest possible leads to minimize inductance and resistive loss. The transformer core is the best available for low loss, low leakage and low distortion. The face is 0.375 inch thick aircraft aluminum.
All parts are assembled with thick rubber gaskets to damp vibration - it is about as dead as a solid block of granite.
The neodymium magnet tips are shaped to focus a symmetrical shaped and maximum strength magnetic field on the ribbon to minimize distortion. The magnet tip is saturated at 1.2 Tesla to minimize distortion.
It has good magnetic shielding and can be within 12 inch of a CRT television
We believe the RAVEN Line Source to best midrange/tweeter presently available.
We are pleased to add IsoAcoustics to our line of products!
The IsoAcoustics ISO-L8R155 Home and Studio Speaker Stands
Fine-tune your sound the way it's meant to be heard
Insights from IsoAcoustics founder Dave Morrison
The IsoAcoustics ISO-L8R155 Speaker Stand Line-Up
IsoAcoustics offers three sizes of audio stand to fit your speakers. Each size is optimized to get the most from your particular speaker system.
Stands can be configured to 3" or 8" in height, with inserts that provide a variety of tilt-up and tilt-down adjustments. In the lowest configuration, the monitor can be tilted down to focus the tweeter to a height below the original supporting surface - providing superior isolation and sound improvement.
Choose your set-up: |
ISO-L8R155 Short In this case, the audio speaker stand is configured for 3" in height. Speaker can also be tilted for optimal listening angle. Usually speakers will be situated on a desktop or table. |
 |
ISO-L8R155 Long Speaker stand is configured for 8" in height. Speaker can also be tilted up or down for exact listening angle. Can also be used for floor applications. |
05/11/2013
*CLIO FW*
High Bandwidth Measurement System
- $2,898.50
Best Sellers
Here's a list of our best selling items. This list is updated dynamically according to what people order from our catalogue of products. Please visit our "On Sale" pages to browse our discounted items. Thanks again for shopping with us.
Now On Sale
We present here products that we offer at a reduced price for various reasons. These items are all new in sealed factory cartons except when noted otherwise. New on sale products will be added shortly; please visit us often. Thank you for shoppong with us!
JANTZEN JDT-1024
Diamond dome tweeter
- $1,999.00
